    Fully Welded Floating Ball Valve Self Cavity Pressure Relief Anti Static

    Ask Lasest Price
    Brand Name : VERVO
    Model Number : Q41F-PN150
    Certification : API/ISO/CE
    Payment Terms : T/T, L/C, D/P, Western Union
    Supply Ability : 400000
    Delivery Time : 30
    • Product Details
    • Company Profile

    Fully Welded Floating Ball Valve Self Cavity Pressure Relief Anti Static

    Product Description

    Fully welded ball valves are manufactured to the latest edition of API Standard 6D and tested to API Standard 598.


    Applicable Standards:

    – Ball Valve design according to API6D, ISO 17292, ASME B16.34

    – Face to Face ASME B16.10, API6D

    – Butt Welded ends ASME B16.25

    – Fire Safety ISO 10497, API 607, API 6FA, BS 6755-2

    – Inspection and test API598, API6D


    Rating:

    – ASME CL150, CL300, CL600, CL900, CL1500


    Temperature Range:

    – -196°C~650°C


    Size Range:

    – 3″~40″


    End Connection:

    – Butt Welded


    Body Material:

    – A105, F304, F316, LF2, F11, F22


    Operation:

    – electric, pneumatic, manual, lever, wrench, gear, hydraulic

    Design Description:

    – High shut-off sealing mechanism and low torque operation

    – Block and bleed function

    – Self-cavity pressure relief

    – Fire safe design

    – Blow out proof stem construction

    – Anti-static design

    – Locking device (for lever handle operation)

    – ISO 5211 actuator mounting

    – Emergency grease injection (option)

    – PN design can be available
