DN50 1500LB Flange Type Hard Seal Manual High Pressure Fixed Ball
Valve 2 Piece Ball Valve Stainless Steel Floating Ball
INTRODUCTION
VERVO Valves manufactures a versatile range of Process Ball Valves in
single, two and three piece constructions. The valves are available
in full-bore and regular-bore designs, in a variety of end
connections and materials to suit customer requirements.
The valves are of floating-ball design where the ball moves towards
the downstream seat, under pressure, to effect a tight seal.
Antistatic feature:
Actuator-mounting flange conforms to ISO 5211
SIL3 Safety Integrity Level for Automated Valves
PRODUCT RANGE
Sizes NPS 1/2 to NPS 4
Class 150 to Class 2500
MATERIALS
Available Forging (A105, A182 F304, F3304L, F316, F316L, A182 F51,
F53, A350 LF2, LF3, LF5) Casting (A216 WCB, A351 CF3, CF8, CF3M,
CF8M, A352 LCB, LCC, LC2, A995 4A. 5A), Inconel, Hastelloy, Monel
DESIGN FEATURES
Full or Reduced Bore
RF, RTJ, or BW
Bolted bonnet
Anti-Static Device
Anti-Blow out Stem
Cryogenic or High Temperature, Extended Stem
Single, two and three piece constructions
Soft and metal-seated
Screwed, socket-weld and flanged ends
Variety of actuation options
Fire-safe to ISO 10497 and API 607
Mirror-finished solid stainless ball
Fine-grained PTFE seats
Cavity Pressure Relief mechanism
Blowout-proof stem
High integrity stem sealing – Belleville springs compensate for
wear and thermal expansions
DESIGN STANDARD
Design & manufacture according to API 6D, API 608, ISO 17292
Face-to-face according to API 6D, ASME B16.10 OR MFG’s standard
End Connection according to ASME B16.5 (RF & RTJ), ASME B16.25 (BW)
Test & inspection according to API 6D, API 598
Fire safe design according to API 6FA, API 607
Also available per NACE MR-0175, NACE MR-0103, ISO 15848
| Model number | Q41H-1500LB |
| Item | Ball valve |
| Certification | CE,TS,ISO9001,ISO14001,ISO18001 |
| Brand | VERVO |
| Power | Manual |
| Connection form | Flange |
| Body material | A182 F304 |
| Medium | Water,Steam,Oil |
| Pressure | 1500LB |
| Temperature | -29~200 |
| Seal form | double seal |
| Feature | Easy disassembly and assembly |
FAQ
1/Do you have any Certification ?
Yes we have ISO9001-2015 and CE/PED according to Directive
2014/68/EU,fire safe certificate,ISO15848-1
2/Can we visit your factory?
Sure, we welcome you to visit our factory , check our production
lines and know more about our strength and quality.
3/Do you have quality control system?
Yes, we have ISO/PED certifications and our own quality control
laboratory.
4/Can you arrange the shipment for us?
Yes, we have designated sea freight and railway freight forwarders
with decades of experiences and we get the best price with earliest
vessel and professional service.
5/Can I get some samples?
We are glad to provide free samples to you, but the express fee
will be on your charge.
6/What is your after-sale service?
We provide after-sale service and offer 100% guarantee on our
products.
7/What is your main products?
Valve, and in order to meet different needs, we expanded our
business, we also do sanitary type products.
8/Are you trading company or manufacturer
We are factory, and welcome to visit our factory
9/What is your MOQ
No MOQ, As your request .Normal size and material we have stock
